Cemented Carbide Composite Rolls

Product Information

Specialized Materials: We utilize special cemented carbide grades designed for hot rolling rods and ribbed steel bars.
Secure Hydraulic Locking System: Hydraulic nuts, supplied with oil at 100-200 MPa, generate an axial pre-tightening force of 500-1500 kN. This fastens the cemented carbide roll rings securely to the mother shafts. The system is practical, reliable, and ensures enhanced composite roll ring performance through proper prestress protection.
Sizing Mill Roll Rings: We offer various cemented carbide roll rings for sizing mills, with diameters of φ300-400mm and thicknesses ranging from 30mm to 159mm.
Hot Rolling Solutions: We provide various composite cemented carbide roll rings specifically for hot rolling ribbed steel bars and rods.
Custom Manufacturing Services: Our capabilities include composite roll design, groove machining, and thread processing.
Compatible Tooling: We supply various compatible tools for machining composite cemented carbide roll rings.

INQUIRY

Description

Technical Parameter

1) The rolling quantily of composite cemented carbide rolls

Specification (mm)	The rolling quantityof singlegroove(ton)
Specification (mm)	Stands of finished products K1	The front stands of finished products K2	Slitter K3、K4
φ10	>600	>1500	>3000
φ12	>800	>2000	>4000
φ14	>1400	>3000	>6000
φ16	>1600	>3500	>7000
φ18	>1800	>4000	>8000
φ20	>2000	>5000
φ22	>2200	>6000
φ25	>2500	>8000

2) Cemented carbide composite rolls specifications

Outer diameter range(mm)	Width range(mm)	Rolling size range(mm)
285-480	50-140	5-28

3) Rolling process for hot rolling rods and rebar

Name	Single rolling	2clit rolling	3clit rolling	Recommend materials
K1 Group				Cemented carbide
K2 Group				Cemented carbide
K4 Group				Cemented carbide

Note:

We design and manufacture single-line, two-slit, three-slit, and combined hard alloy rolls to suit the customer's production line and rolling process. These products include wire, bar, and rebar rolls.

The high output of cemented carbide composite rolls significantly reduces roll change frequency and increases unit production.

Our products feature good surface quality, minimal deformation, a high negative tolerance rate, and a high finished product rate.
